CD101F Plus Compact Bluetooth Walkie Talkie Set For Warehouse/Logistics

Features:

• Bluetooth Walkie Talkie & Bluetooth Wireless earphone
• Compact design
• Bright Torchlight
• 2000mAh Large Battery Capacity walkie talkie + 180mAh earphone
• Rugged Construction
• Type-C Charging
• VOX hands-free
• Alarm function
• Wireless copy function

Applications:

• Outdoor
• Warehouse
• Construction Sites
• Supermarket
• Event Planning

Chierda CD101F plus is a bundle of a Bluetooth walkie talkie and a Bluetooth earpiece. This bundle is designed for those situations where users require hands-free operation, including restaurants, hotels, and construction sites. CD101F features rugged construction and a long-lasting battery. The wireless earpiece delivers crystal clear sound when in noisy environments.

Comfortable Ear-hook Earphone

EB121 wireless earphone comes with an ear hook. This design allows you to wear the earphone and make sure the one don’t fall out.

Extended Battery Life

CD101F is equipped with a 2000mAh rechargeable lithium battery. This walkie talie bundle can outlast for 180 hours on standby. It takes 5 hours to charge fully.

Splashproof, Dustproof, Drop-resistant

CD101F housing is made of military quality material. With an IP54 rating, it can be splashproof and dustproof.

Powerful Clarity

CD101F is upgraded with an anti-magnetic speaker. It deliver crisp clear sound.

Bluetooth 5.0

EB121 Bluetooth earpiece can be connected to the walkie talkie within a range of 10 meters. The connection is stable and solid.

Standard Package:

• Radio*1
• Battery*1
• EB121 Bluetooth Earpiece*1
• Strap*1
• Belt Clip*1
• Antenna*1
• Charging cradle*1

Technical Data:

SPECIFICATION		TRANSMITTER		RECEIVER
Frequency Range	UHF:400-480MHz	Output Power	≤2W	RF Sensitivity	≤0.25uV/≤0.3uV
Channel Spacing	16	Current	≤1.5A	Silent Sensitivity	≤ 0.2uV/≤0.25uV
Memory Channel	12.5 KHz/ 25 KHz	Modulation Distortion	<5%(300-3000Hz)	Audio Frequency Power	≥300mW
Rated Voltage	3.7V	Maximum Frequency Deviation	≤ 5KHz/ ≤ 2.5KHz	Audio Distortion	≤5%
Battery Capacity	2000mAh	CTCSS Frequency Deviation	0.75KHz±50Hz
Frequency Sensitivity	±2.5ppm	Remanent Radiation	≤ 7uW	Spurious Rejection	≥55dB
Antenna Impedance	50Ω	Modulation Mode	FM	Selectivity	≥ 65dB
Dimension	106x61x34mm (without antenna )			Intermodulation	≥60dB

Resources:

→Download CD101F Plus brochure

FAQ

Question 1: Is this compatible with any Bluetooth earpiece?
Answer 1: No, CD101F is not compatible with other Bluetooth headsets except the Bluetooth headset that comes with it.
Question 2: How far will the bluetooth eaphone achieve?
Answer 2: They can do a good job within 6 meters. If the distance is over 6 meters, the signal will be delayed or weakened.
Question 3: Will it work with other radios?
Answer 3: Yes, it can work with other radios. Please make sure they have the same frequency and CTCSS/DCS on the same channel, then they will work together.
