Features:
- 10W High Power Analog Radio, Long Range Talk
- IP67 Waterproof and Dustproof
- Rugged and Reinforced Housing
- AI-based Noise Cancelling
- One-key Group Call
- Repeater Capable
- Alarm function
- VOX hands-free function
Application:
- Outdoor
- Warehouse
- Transportation
- Construction Sites
Standard Package:
- Radio*1
- Antenna*1
- Battery*1
- Belt Clip*1
- Hand Strap*1
- Users’ Manual*1
- Charger*1
Chierda TC368 is a 10W high output power handheld radio. The strong signal easily penetrates thick walls and metal structures. It is waterproof and dustproof, which can be use in harsh environments. It features an advanced noise-cancelling function.
Repeater Capable
TC368 walkie talkie is repeater capable to extend communication range. You can pair TC368 with Chierda portable repeater V9 to extend signal coverage at construction sites and other open areas.
AI-based Noise Reduction
TC368 walkie-talkie adopts AI-based noise reduction technology. By filtering noise from the background, it can not only deliver clearer sound to the receiver, but also receive a clearer sound. That process is called two-way noise reduction. Even in factories with extreme background noise, human voices remain clear to ensure instructions are issued accurately on the first attempt.
IP67 Waterproof
TC368 walkie talkie is under rigorous tests before it leaves the factory. We make sure it can be IP67 rated waterproof and dustproof. It can be submerged in water 1 meter deep for 30 minutes without water ingress, and completely seals out dust and fine particles. Reduce hardware damage caused by moisture or dust.
Long-lasting Battery Life
TC368 radio is equipped with 2800mAh battery and power saving function. Supports over 12 hours of high-intensity continuous talk time, with a standby time exceeding 120 hours.
Cancel CTCSS/DCS
You can communicate with co-workers without worrying about intercommunication problems from CTCSS/DCS differences, helping the work run fast.
Emergency Alert
If you run into an emergency, you can long press the red alarm button on the top. The radio will send a local alert. You can also program the radio to send a remote alert.
VOX Hands-free Function
You can activate VOX function by programming. When you start it, you can totally realize hands-free operation. You can also adjust the sensitivity.
Technical Data:
| SPECIFICATION | TRANSMITTER | RECEIVER | |||
| Frequency Range | VHF:136-174MHz or UHF:400-480MHz |
Output Power | 10W | RF Sensitivity | ≤ 0.25uV/ ≤ 0.3uV |
| Channel Spacing | 16 | Current | ≤2.5A | Silent Sensitivity | ≤0.2uV/≤0.25uV |
| Memory Channel | 12.5 KHz / 25 KHz | Modulation Distortion | <5%(300-3000Hz) | Audio Frequency Power | ≥500mW |
| Rated Voltage | 7.4V DC | Maximum Frequency Deviation |
≤ 5KHz/≤ 2.5KHz | Audio Distortion | ≤5% |
| Battery Capacity | 2800mAh | CTCSS Frequency Deviation |
0.75KHz± 50Hz | Modulation Receiver Bandwidth |
±7KHz |
| Frequency Sensitivity | ± 2.5ppm | Remanent Radiation | ≤7uW | Spurious Rejection | ≥55dB |
| Antenna Impedance | 50Ω | Modulation Mode | 16K∅F3E/11K∅F3E | Selectivity | ≥65dB |
| Dimension | 126.5x57x37.9mm (Without Antenna) |
Remanent Modulation | ≤-35dB | Intermodulation | ≥60dB |
Resources:
→Download TC368 brochure
