CD21 2W Portable Rugged Two Way Radio

Features:

• Rugged and Durable
• High-gain Antenna
• Portable and thin
• Frequency Hopping, Scrambler
• Type-C Charging

Application:

• Security
• Entertainment
• Hotel

Standard Package:

• Radio*1
• Antenna*1
• Battery*1
• Belt Clip*1
• Hand Strap*1
• Charger*1
• User’s manual*1

Chierda CD21 walkie talkie features rugged construction and good quality. It is designed for use in construction sites and other harsh environments.

Powerful Penetration

With 2 watt output power, CD21 walkie talkie can reach 1-3km in open areas.

Wide Application

CD21 walkie talkie has a wide applications, such as security teams, warehouses, and construction sites.

Enhanced Antenna

CD21 is equipped with a HD copper antenna which has a wider range and stronger penetration.

Rugged Construction

CD21 housing is made of sturdy PC material, which has high strength. It is shock-proof and dustproof.

Technical Data:

SPECIFICATION		TRANSMITTER		RECEIVER
Frequency Range	VHF:136-174MHz or UHF:400-480MHz	Output Power	2W	RF Sensitivity	≤ 0.25uV/ ≤ 0.3uV
Channel Spacing	16	Current	≤1.2A	Silent Sensitivity	≤0.2uV/≤0.25uV
Memory Channel	12.5 KHz / 25 KHz	Modulation Distortion	<5%(300-3000Hz)	Audio Frequency Power	≥300mW
Rated Voltage	3.7V DC	Maximum Frequency Deviation	≤ 5KHz/≤ 2.5KHz	Audio Distortion	≤5%
Battery Capacity	1000mAh/2000mAh/3000mAh (Optional)	CTCSS Frequency Deviation	0.75KHz± 50Hz	Modulation Receiver Bandwidth	±7KHz
Frequency Sensitivity	± 2.5ppm	Remanent Radiation	≤7uW	Spurious Rejection	≥55dB
Antenna Impedance	50Ω	Modulation Mode	16K∅F3E/11K∅F3E	Selectivity	≥65dB
Dimension	95x52x32mm (Without Antenna)	Remanent Modulation	≤-35dB	Intermodulation	≥60dB

Resources:

→Download CD21 User’s Manual & Programming software
