Feature:
- IP67 Waterproof and Dustproof
- 10W High Power, 1-10km Talk Coverage, Long Range Handheld Radio
- LED Hidden Display
- Two-way Noise Reduction
- 2800mAh Large battery capacity
- One-key All Call
- Emergency SOS Button
- Wireless Replication, Quick Pairing
- High/Low Power Selection
Application:
- Construction Site
- Outdoor Activities: kayaking, fishing…
- Farm
- Logistics
Standard Pack:
- TC368PLUS Radio*1
- Battery*1
- Belt Clip*1
- Hand Strap*1
- Charger Set*1
- User’s Manual *1
Long Range Radio
Chierda TC368plus is a 10-watt high-power handheld radio. It can reach a long range of up to 10 kilometer in open areas. If you want a extended communication range, you can consider to invest a portable repeater V9. This combo can reach 20 kilometer at least.
Two Way Noise Reduction Function
Unlike normal walkie talkies which use single-channel noise reduction technology, TC368plus radio is more suitable for various noisy environments.
Long Battery Life
TC368plus is equipped with a 2800mAh rechargeable battery. In addition, it has a power saving function. You can continuously use walkie talkie up to 12 hours.
Technical Data:
| SPECIFICATION | TRANSMITTER | RECEIVER | |||
| Frequency Range | VHF:136-174MHz or UHF:400-480MHz |
Output Power | 10W | RF Sensitivity | ≤ 0.25uV/ ≤ 0.3uV |
| Channel Spacing | 16 | Current | ≤2.5A | Silent Sensitivity | ≤0.2uV/≤0.25uV |
| Memory Channel | 12.5 KHz / 25 KHz | Modulation Distortion | <5%(300-3000Hz) | Audio Frequency Power | ≥500mW |
| Rated Voltage | 7.4V DC | Maximum Frequency Deviation |
≤ 5KHz/≤ 2.5KHz | Audio Distortion | ≤5% |
| Battery Capacity | 2800mAh | CTCSS Frequency Deviation |
0.75KHz± 50Hz | Modulation Receiver Bandwidth |
±7KHz |
| Frequency Sensitivity | ± 2.5ppm | Remanent Radiation | ≤7uW | Spurious Rejection | ≥55dB |
| Antenna Impedance | 50Ω | Modulation Mode | 16KøF3E/ 11KøF3E | Selectivity | ≥65dB |
| Dimension | 126.5×66.6×37.9mm (Without Antenna) |
Remanent Modulation | ≤-35dB | Intermodulation | ≥60dB |
Resources:
→Download TC368plus Brochure
→Download TC368plus Programming software
