Features:
- 10W Digital Radio
- 2500mAh Large Capacity Battery
- Alarm Mode
- VOX Hands-free Function
- Tail Sound Elimination
- Wireless Repulication
- Squelch
- Powerful Flashlight
Application:
- Outdoor
- Fishing
- Security
- Warehouse
Standard Package:
- Radio*1
- Battery*1
- Charger*1
- Belt clip*1
- Strap*1
- Antenna*1
- User’s manual*1
Technical Data:
| SPECIFICATION | TRANSMITTER | RECEIVER | |||
| Frequency Range | VHF:136-174MHz UHF:400-480MHz |
Output Power | 10W | RF Sensitivity | ≤ 0.25uV/ ≤ 0.3uV |
| Channel | 128 | Current | ≤2.5A | Silent Sensitivity | ≤0.2uV/≤0.25uV |
| Memory Channel | 12.5 KHz / 25 KHz | Modulation Distortion | ＜5%(300-3000Hz) | Audio Frequency Power | ≥500mW |
| Rated Voltage | 7.4V DC | Maximum Frequency Deviation |
≤ 5KHz/≤ 2.5KHz | Audio Distortion | ≤5% |
| Battery Capacity | 2500mAh | CTCSS Frequency Deviation |
0.75KHz± 50Hz | Modulation Receiver Bandwidth |
±7KHz |
| Frequency Sensitivity | ± 2.5ppm | Remanent Radiation | ≤7uW | Spurious Rejection | ≥55dB |
| Antenna Impedance | 50Ω | Modulation Mode | 16K∅F3E/11K∅F3E | Selectivity | ≥65dB |
| Dimension | 119x54x37mm (Without Antenna) |
Remanent Modulation | ≤-35dB | Intermodulation | ≥60dB |
