Features:
- Bluetooth walkie talkie and Bluetooth earpiece
- 10W high power two way radio for long range
- Crystal clear sound
- Built-in LED hidden display, high visibility
- Powerful Flashlight
- 2600mAh rechargeable battery
- Wireless Copy
- Local/Romote Alarm
Application:
- Outdoor
- Construction sites
- Warehouses
- Supermarket
- Security
Standard Package:
- CD-108F radio*1
- EB121 Bluetooth earpiece*1
- Battery *1
- Hand Strap *1
- Belt clip*1
- Antenna*1
- Charger*1
CD108F is a 10 watt high-power and high performance walkie talkie with a built-in Bluetooth module. CD108F plus is a bundle of CD108F and EB121 wireless Bluetooth earpiece. It is an ideal option for use in warehouses, public safety, and security team.
Bluetooth 5.0 Module
Both CD108F walkie talkie and EB121 earpiece are equipped with Bluetooth 5.0 chip. The connection is stable and quick.
Excellent Performance
CD108F Plus is a cost-effective and feature-rich model. The headset is comfortable to wear for a long time.
Techinical Data:
| SPECIFICATION | TRANSMITTER | RECEIVER | |||
| Frequency Range | VHF:136-174MHz or UHF:400-480MHz |
Output Power | 10W | RF Sensitivity | ≤0.25uV /≤0.3uV |
| Channel Spacing | 16 | Current | ≤2.5A | Silent Sensitivity | ≤0.2uV/≤0.25uV |
| Memory Channel | 12.5 KHz / 25 KHz | Modulation Distortion | ＜5%(300-3000Hz) | Audio Frequency Power | ≥300mW |
| Rated Voltage | 7.4V DC | Maximum Frequency Deviation | ≤5KHz / ≤2.5KHz | Audio Distortion | ≤5% |
| Battery Capacity | 2500mAh | CTCSS Frequency Deviation |
0.75KHz±50Hz | Modulation Receiver Bandwidth |
±7KHz |
| Frequency Sensitivity | ±2.5ppm | Remanent Radiation | ≤7uW | Spurious Rejection | ≥55dB |
| Antenna Impedance | 50Ω | Modulation Mode | 16K∅F3E/11K∅F3E | Selectivity | ≥65dB |
| Dimension | 119x54x37 mm (Without Antenna) |
Remanent Modulation | ≤-35dB | Intermodulation | ≥60dB |
Resources:
→Download CD108F Plus Brochure
