Features:
- 1.3 inch Hidden Display, User-friendly Handheld Radio
- 2000mAh Large Capacity Battery
- Type-C Charging
- Powerful LED Flashlight
- Rugged Construction
- Anti-break Code
- Shockproof and drop-resistent
- Set up CTCSS/DCS, one key to cancel CTCSS
- Easy Pairing
Application:
- Outdoor
- Family Camping
- Warehouse
- School
Standard pack:
- Radio*1
- Antenna*1
- Charging cradle*1
- Battery*1
- Belt clip*1
- Hand strap*1
- Users’ Manual*1
Chierda CD101H is designed for outdoor enthusiasts. Unlike other no-display walkie talkies, users can intuitively see the current channel number and the rest of the battery power through a 1.3-inch hidden screen. With a powerful LED flashlight, you can You can have a safe and great trip with CD101H handheld radio.
Long Battery Life
CD101H is equipped with a 2000mAh rechargeable Li-ion battery with up to 21 hours of long-term work. It has a universal Type-C charging port. The charging is convenient. You can charge it directly via a USB-C charging cable, or a desktop charger.
Rugged Construction
Made from PPC+ABC material, CD101H is durable and robust. It can withstand drop from the high.
Technical Data:
| SPECIFICATION | TRANSMITTER | RECEIVER | |||
| Frequency Range | VHF:136-174MHz or
UHF:400-480MHz |
Output Power | ≤2W | RF Sensitivity | ≤0.25uV/≤0.3uV |
| Channel Spacing | 16 | Current | ≤1.3A | Silent Sensitivity | ≤ 0.2uV/≤0.25uV |
| Memory Channel | 12.5 KHz/ 25 KHz | Modulation Distortion | <5%(300-3000Hz) | Audio Frequency Power | ≥300mW |
| Rated Voltage | 3.7V | Maximum Frequency Deviation | ≤ 5KHz/ ≤ 2.5KHz | Audio Distortion | ≤5% |
| Battery Capacity | 2000mAh | CTCSS Frequency Deviation | 0.75KHz±50Hz | ||
| Frequency Sensitivity | ±2.5ppm | Remanent Radiation | ≤ 7uW | Spurious Rejection | ≥55dB |
| Antenna Impedance | 50Ω | Modulation Mode | FM | Selectivity | ≥ 65dB |
| Dimension | 106x61x34mm (without antenna ) |
Intermodulation | ≥60dB | ||
